Key Commercial Data
| Orderkey | 1456048 |
|---|---|
| Packing unit | 20 pc |
| Minimum order quantity | 20 pc |
| Catalog page | Page 228 (C-2-2013) |
| GTIN | 4046356605915 |
| Weight per Piece (excluding packing) | 6.390 g |
| Custom tariff number | 85366990 |
| Country of origin | DE (Germany) |
General
| Rated current at 40°C | 4 A |
|---|---|
| Rated voltage | 50 V AC |
| 60 V DC | |
| Rated surge voltage | 1.5 kV |
| Number of positions | 4 |
| Insulation resistance | ≥ 100 MΩ |
| Coding | A – standard |
| Standards/regulations | M8 connector IEC 61076-2-104 |
| Status display | No |
| Overvoltage category | II |
| Degree of pollution | 3 |
| Connection method | Solder pins |
| Torque | 1 Nm … 1.5 Nm (Installation-side) |
| Mounting type | Rear mounting M8 x 1 With flat nut |
Material
| Flammability rating according to UL 94 | HB |
|---|---|
| Contact material | Cu alloy |
| Contact surface material | Au |
| Contact carrier material | PA 6.6 |
| Material, knurls | Zinc die-cast, nickel-plated |
| Sealing material | NBR |
Cable
| Standards/specifications | M8 connector IEC 61076-2-104 |
|---|---|
| Ambient temperature (operation) | -25 °C … 85 °C |
Standards and Regulations
| Standard designation | M8 connector |
|---|---|
| Standards/regulations | IEC 61076-2-104 |
| Flammability rating according to UL 94 | HB |
