Key Commercial Data
| Orderkey | 2862385 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 188 (C-6-2017) |
| GTIN | 4017918923860 |
| Weight per Piece (excluding packing) | 500.000 g |
| Custom tariff number | 85389091 |
| Country of origin | DE (Germany) |
Dimensions
| Dimensional drawing | |
|---|---|
| Caption | The figure shows the general dimensional drawing of the Inline Block IO product family |
| Width | 156 mm |
| Height | 141 mm |
| Depth | 57 mm |
| Note on dimensions | Specfications with connectors |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 85 °C |
| Permissible humidity (operation) | max. 85 % (non-condensing) |
| Permissible humidity (storage/transport) | 95 % (non-condensing) |
| Air pressure (operation) | 80 kPa … 108 kPa (up to 2000 m above sea level) |
| Air pressure (storage/transport) | 66 kPa … 108 kPa (up to 3500 m above sea level) |
| Degree of protection | IP20 |
General
| Mounting type | DIN rail |
|---|---|
| Net weight | 500 g |
| Note on weight specifications | with connectors |
| Mounting type | NS 35/7,5 |
Interfaces
| Designation | INTERBUS |
|---|---|
| Connection method | Inline shield connector |
| Transmission speed | 500 kbps |
