Key Commercial Data
| Orderkey | 2829904 |
|---|---|
| Packing unit | 10 pc |
| Minimum order quantity | 10 pc |
| Catalog page | Page 77 (IF-2002) |
| GTIN | 4017918101152 |
| Weight per Piece (excluding packing) | 27.000 g |
| Custom tariff number | 85369010 |
| Country of origin | PL (Poland) |
General
| Number of positions | 2 |
|---|---|
| Nominal voltage UN | 400 V (voltage is determined by the coupling connector.) |
| Nominal current IN | 16 A (current is determined by the coupling connector.) |
| Color | gray |
| Insulating material | PA |
Connection data
| Conductor cross section solid min. | 0.5 mm² |
|---|---|
| Conductor cross section solid max. | 6 mm² |
| Conductor cross section flexible min. | 0.4 mm² |
| Conductor cross section flexible max. | 4 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 10 |
| Connection method | Spring-cage connection |
| Stripping length | 14 mm |
Environmental Product Compliance
| China RoHS | Environmentally Friendly Use Period = 50 |
|---|---|
| For details about hazardous substances go to tab “Downloads”, Category “Manufacturer’s declaration” |
