Key Commercial Data
| Orderkey | 2700307 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 17 (C-6-2017) |
| GTIN | 4046356547949 |
| Weight per Piece (excluding packing) | 1,237.000 g |
| Custom tariff number | 84714100 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Dimensions
| Outer dimensions: width, height, depth | 203 mm x 147 mm x 5 mm (Dimensions of the front plate) |
|---|---|
| Installation dimensions: width, height, depth | 195 mm x 139 mm x 54 mm (Installation cutout) |
Display
| Display | 17.8 cm/7″ TFT |
|---|---|
| Brightness | 350 cd/m², typical (adjustable) |
| Screen resolution | 800 x 480 Pixel(s) (WVGA) |
| Backlighting | LED |
| Display backlight MTBF | > 50000 h |
| Touch technology | analog resistive (polyester) |
| Colors | 65536 colors |
Computer data
| Processor | Arm9™, 200 MHz |
|---|---|
| Operating system | Windows®CE 5.0 |
| User software | MicroBrowser |
| RAM | 64 MB SDRAM |
| Mass storage | Flash, 32 MB |
| Network | 1 x Ethernet (10/100 Mbps), RJ45 |
| Interfaces | 2x USB host 2.0 |
| Bus system | without |
General
| Material front plate | Aluminum (natural anodized) |
|---|---|
| Housing material | Steel sheet, zinc-plated |
| Mounting type | Front installation |
| Weight | 1000 g |
