Key Commercial Data
| Orderkey | 0613015 |
|---|---|
| Packing unit | 4 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 351 (CL-2005) |
| GTIN | 4017918003203 |
| Weight per Piece (excluding packing) | 727.680 g |
| Custom tariff number | 85369010 |
| Country of origin | PL (Poland) |
General
| Number of levels | 1 |
|---|---|
| Number of connections | 240 |
| Color | green |
| Insulating material | PA/F |
| Flammability rating according to UL 94 | HB |
| Rated surge voltage | 4 kV |
| Degree of pollution | 3 |
| Overvoltage category | III |
| Insulating material group | I |
| Connection in acc. with standard | IEC / EN |
| Nominal current IN | 10 A (current data for slip-on connections in acc. with EN 61210 are also dependent on nominal size, material, insulation of the sleeve and conductor cross section.) |
| Maximum load current | 10 A |
| Nominal voltage UN | 400 V (voltage data for slip-on connections in acc. with EN 61210 are also dependent on nominal size, material, insulation of the sleeve and conductor cross section.) |
| Open side panel | No |
| Number of positions | 80 |
Standards and Regulations
| Connection in acc. with standard | IEC / EN |
|---|---|
| Flammability rating according to UL 94 | HB |
Connection data
| Connection method | Slip-on connection |
|---|---|
| Connection in acc. with standard | IEC / EN |
| Conductor cross section solid min. | 0.5 mm² |
| Conductor cross section solid max. | 2.5 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 14 |
| Conductor cross section flexible min. | 0.5 mm² |
| Conductor cross section flexible max. | 2 mm² |
| Min. AWG conductor cross section, flexible | 24 |
| Max. AWG conductor cross section, flexible | 14 |
| Slip-on connection | 6.3/2.8 x 0.8 mm |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
