Dimensions
| Outer dimensions: width, height, depth | 400 mm x 305 mm x 66 mm |
|---|---|
| External dimension, width | 400 mm |
| External dimension, height | 305 mm |
| External dimension, depth | 66 mm |
Display
| Display | 38.1 cm/15″ TFT |
|---|---|
| Screen resolution | 1024 x 768 Pixel(s) (XGA) |
| Backlighting | LED |
| Display backlight MTBF | > 50000 h |
| Touch technology | analog resistive (polyester) |
| Colors | 16.2 million colors |
Computer data
| Processor | Intel® Atom™ N2600 1.6 GHz |
|---|---|
| Cooling | passive |
| Operating system | Windows® Embedded Standard 7 (32-Bit), Multi-language |
| User software | without user software |
| RAM | 4 GB DDR3 SODIMM |
| Mass storage | mSATA SSD (MLC) WT, 128 GB |
| Network | 2x Ethernet (10/100/1000 Mbps), RJ45 |
| Interfaces | 1x COM (RS-232) |
| 4x USB 2.0 (1x USB on the front with IP65 cover (can be deactivated via software)) | |
| Slots | without slots |
| Service life of battery | 3 … 5 years (typ.) |
General
| Optional operating keys | 6 additional keys (on/off button, software keyboard, switch task Alt + ESC, right mouse button, user-specific function, SHIFT key (brightness and volume)) |
|---|---|
| Front cover | Plastic, painted |
| Housing material | Aluminum die-cast |
| Mounting type | VESA MIS-D, 75 (integrated in back panel as a mounting option) |
| Weight | 4300 g |
