Key Commercial Data
| Orderkey | 2905525 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 496 (C-5-2017) |
| GTIN | 4046356960052 |
| Weight per Piece (excluding packing) | 333.330 g |
| Custom tariff number | 85444290 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 80 °C |
General
| Max. permissible operating voltage | 250 V AC/DC |
|---|---|
| Max. permissible current | 6 A (per single wire at 40°C) |
| 4 A (per single wire at 60°C) | |
| Max. permissible total current | 20 A (per cable at 40 °C) |
| 16 A (per cable at 60°C) | |
| Mounting position | any |
| Nominal operating mode | 100% operating factor |
| Degree of protection | IP20 |
Connection data 1
| Connection name | Controller level |
|---|---|
| Connection method | Plug connection |
| Note | Can be plugged onto 40-pos. I/O modules |
Connection data 2
| Connection name | Field level |
|---|---|
| Connection method | COMBICON connectors |
| Number of connections | 4 |
| Number of positions | 10 |
| Pitch | 3.5 mm |
Cable
| Conductor construction: Number of litz wires: | 16 |
|---|---|
| Single wire, material | Cu uninsulated |
| Single wire, cross section | 0.5 mm² |
| External diameter | 9 mm |
| Length of cable | 8 m |
| Max. conductor resistance | ≤ 39 Ω/km |
