Key Commercial Data
| Orderkey | 2315256 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 268 (C-4-2017) |
| GTIN | 4046356313360 |
| Weight per Piece (excluding packing) | 116.900 g |
| Custom tariff number | 85369010 |
| Country of origin | US (United States) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
General
| Nominal voltage UN | 250 V AC/DC |
|---|---|
| Max. current carrying capacity per branch | 15 A |
| Total current | 30 A (per potential) |
| Potential connections | Per potential (P1, P2) 2 power/8 distributor terminal blocks |
| Mounting position | any |
| Standards/regulations | IEC 60664 |
| DIN EN 50178 | |
| Rated surge voltage | 2.2 kV |
| Degree of pollution | 2 |
| Overvoltage category | III |
Connection data, supply
| Connection method | Screw connection |
|---|---|
| Stripping length | 8 mm |
| Screw thread | M3 |
| Conductor cross section solid | 0.2 mm² … 6 mm² |
| Conductor cross section flexible | 0.2 mm² … 4 mm² |
| Conductor cross section AWG | 24 … 10 |
| Number of connections | 2 |
Connection data, distribution
| Connection method | Screw connection |
|---|---|
| Stripping length | 8 mm |
| Screw thread | M3 |
| Conductor cross section solid | 0.2 mm² … 4 mm² |
| Conductor cross section flexible | 0.2 mm² … 2.5 mm² |
| Conductor cross section AWG | 24 … 12 |
| Number of connections | 16 |
