Key Commercial Data
| Orderkey | 2322401 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 576 (C-5-2017) |
| GTIN | 4046356451703 |
| Weight per Piece (excluding packing) | 108.100 g |
| Custom tariff number | 85366990 |
| Country of origin | US (United States) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
General
| Max. perm. operating voltage | 25 V AC |
|---|---|
| 60 V DC | |
| Max. perm. current (per branch) | 1 A |
| Number of positions | 15 |
| Status display | No |
| Mounting position | any |
Connection data for connection 1
| Connection name | Field level |
|---|---|
| Connection in acc. with standard | IEC / EN |
| Connection method | Screw connection |
| Stripping length | 8 mm |
| Screw thread | M3 |
| Conductor cross section solid | 0.2 mm² … 4 mm² |
| Conductor cross section flexible | 0.2 mm² … 2.5 mm² |
| Conductor cross section AWG | 24 … 12 |
| Number of positions | 15 |
Connection data for connection 2
| Connection name | Controller level |
|---|---|
| Connection method | High-density D-SUB socket strip |
| Number of connections | 1 |
| Number of positions | 15 |
