Key Commercial Data
| Orderkey | 1607274 |
|---|---|
| Packing unit | 5 pc |
| Catalog page | Page 32 (C-2-2013) |
| GTIN | 4017918941024 |
| Weight per Piece (excluding packing) | 53.370 g |
| Custom tariff number | 85366990 |
| Country of origin | PL (Poland) |
General
| Connection technology | Screw connection |
|---|---|
| Connection method | Screw connection |
| Tightening torque | 0.2 Nm … 0.25 Nm |
| Degree of pollution | 3 |
| Number of positions | 39+PE |
| Insertion/withdrawal cycles | ≥ 100 |
| Size | VC4 |
| Conductor cross section solid min. | 0.14 mm² |
| Conductor cross section solid max. | 1.5 mm² |
| Conductor cross section flexible min. | 0.14 mm² |
| Conductor cross section flexible max. | 0.75 mm² |
| Conductor cross section | 0.14 mm² … 1.5 mm² |
| Connection cross section AWG | 30 … 14 |
| Stripping length of the individual wire | 7 mm |
Material data
| Housing material | PA 6.6 |
|---|---|
| Contact material | CuZn |
| Contact surface material | Tin-plated |
| Contact carrier material | PA |
Electrical characteristics
| Rated voltage (III/3) | 160 V |
|---|---|
| Nominal voltage UN | 160 V |
| Rated surge voltage | 2.5 kV |
| 2.5 kV | |
| Rated current | 10 A |
| 10 A | |
| Nominal current IN | 10 A |
