Key Commercial Data
| Orderkey | 1607167 |
|---|---|
| Packing unit | 5 pc |
| Minimum order quantity | 5 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 32 (C-2-2013) |
| GTIN | 4017918940942 |
| Weight per Piece (excluding packing) | 53.200 g |
| Custom tariff number | 85366990 |
| Country of origin | PL (Poland) |
General
| Connection technology | Screw connection |
|---|---|
| Connection method | Screw connection |
| Tightening torque | 0.5 Nm … 0.6 Nm |
| Degree of pollution | 3 |
| Number of positions | 7+PE |
| Insertion/withdrawal cycles | ≥ 100 |
| Size | VC3 |
| Conductor cross section solid min. | 0.2 mm² |
| Conductor cross section solid max. | 2.5 mm² |
| Conductor cross section flexible min. | 0.2 mm² |
| Conductor cross section flexible max. | 1.5 mm² |
| Conductor cross section | 0.2 mm² … 4 mm² |
| Connection cross section AWG | 24 … 12 |
Material data
| Housing material | PA |
|---|---|
| Contact material | CuZn |
| Contact surface material | Tin-plated |
| Contact carrier material | PA |
Electrical characteristics
| Rated voltage (III/3) | 400 V |
|---|---|
| Nominal voltage UN | 400 V |
| Rated surge voltage | 6 kV |
| 6 kV | |
| Rated current | 20 A |
| 20 A |
