Key Commercial Data
| Orderkey | 1607481 |
|---|---|
| Packing unit | 5 pc |
| Minimum order quantity | 5 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 33 (C-2-2013) |
| GTIN | 4017918969134 |
| Weight per Piece (excluding packing) | 77.560 g |
| Custom tariff number | 85366990 |
| Country of origin | PL (Poland) |
General
| Note | Connectors may only be connected/disconnected when under no load. |
|---|---|
| Connection technology | Screw connection |
| Connection method | Screw connection |
| Tightening torque | 1.2 Nm … 1.8 Nm |
| Degree of pollution | 3 |
| Number of positions | 6+PE |
| Insertion/withdrawal cycles | ≥ 50 |
| Size | VC4 |
| Conductor cross section AWG min. | 20 |
| Conductor cross section AWG max. | 6 |
| 2 conductors with same cross section, solid min. | 0.5 mm² |
| 2 conductors with same cross section, solid max. | 6 mm² |
| 2 conductors with same cross section, stranded min. | 0.5 mm² |
| 2 conductors with same cross section, stranded max. | 4 mm² |
| Conductor cross section | 0.5 mm² … 16 mm² |
| Connection cross section AWG | 20 … 6 |
| Stripping length of the individual wire | 14 mm |
Material data
| Housing material | PA |
|---|---|
| Contact material | CuZn |
| Contact surface material | hard-silver plated |
| Contact carrier material | PA |
Electrical characteristics
| Rated voltage (III/3) | 690 V |
|---|---|
| Rated surge voltage | 6 kV |
| 6 kV | |
| Rated current | 70 A |
| 70 A |
Standards and Regulations
| Connection in acc. with standard | CUL |
|---|---|
| Flammability rating according to UL 94 | V0 |
