Key Commercial Data
| Orderkey | 3048360 |
|---|---|
| Packing unit | 10 pc |
| Minimum order quantity | 10 pc |
| Catalog page | Page 468 (C-1-2017) |
| GTIN | 4017918976279 |
| Weight per Piece (excluding packing) | 115.930 g |
| Custom tariff number | 85363030 |
| Country of origin | DE (Germany) |
General
| Number of levels | 1 |
|---|---|
| Number of connections | 2 |
| Nominal cross section | 35 mm² |
| Color | light gray |
| Insulating material | Duroplast |
| Flammability rating according to UL 94 | V0 |
| Maximum power dissipation for nominal condition | 4.06 W |
| Fuse | D 02 / E 18 |
| Fuse type | Screw cartridge |
| Rated surge voltage | 6 kV |
| Degree of pollution | 2 |
| Overvoltage category | III |
| Insulating material group | IIIa |
| Maximum load current | 63 A (with 35 mm² conductor cross section) |
| Nominal current IN | 63 A (the current is determined by the fuse used) |
| Nominal voltage UN | 400 V (the voltage is determined by the fuse used) |
| Open side panel | No |
| Shock protection test specification | DIN EN 50274 (VDE 0660-514):2002-11 |
| Back of the hand protection | guaranteed |
| Finger protection | guaranteed |
| Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)) | 165 °C |
Connection data
| Conductor cross section solid min. | 1.5 mm² |
|---|---|
| Conductor cross section solid max. | 35 mm² |
| Conductor cross section flexible min. | 1.5 mm² |
| Conductor cross section flexible max. | 35 mm² |
| Conductor cross section AWG min. | 16 |
| Conductor cross section AWG max. | 2 |
| Conductor cross section flexible, with ferrule without plastic sleeve min. | 1.5 mm² |
| Conductor cross section flexible, with ferrule without plastic sleeve max. | 25 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve min. | 1.5 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve max. | 25 mm² |
| Cross section with insertion bridge, solid max. | 25 mm² |
| Cross section with insertion bridge, stranded max. | 25 mm² |
| 2 conductors with same cross section, solid min. | 1.5 mm² |
| 2 conductors with same cross section, solid max. | 10 mm² |
| 2 conductors with same cross section, stranded min. | 1.5 mm² |
| 2 conductors with same cross section, stranded max. | 10 mm² |
| 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min. | 1.5 mm² |
| 2 conductors with same cross section, stranded, ferrules without plastic sleeve, max. | 10 mm² |
| 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min. | 1.5 mm² |
| 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max. | 10 mm² |
| Cross section with insertion bridge, solid max. | 25 mm² |
| Cross section with insertion bridge, stranded max. | 25 mm² |
| Connection method | Screw connection |
| Stripping length | 19 mm |
| Internal cylindrical gage | B8 |
| Screw thread | M6 |
| Tightening torque, min | 3.5 Nm |
| Tightening torque max | 4 Nm |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
