Key Commercial Data
| Orderkey | 2320380 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 284 (C-4-2017) |
| GTIN | 4046356599030 |
| Weight per Piece (excluding packing) | 3,528.000 g |
| Custom tariff number | 85322900 |
| Country of origin | CN (China) |
Ambient conditions
| Degree of protection | IP20 |
|---|---|
| Ambient temperature (operation) | -40 °C … 60 °C |
| Ambient temperature (storage/transport) | -40 °C … 60 °C |
| Max. permissible relative humidity (operation) | ≤ 95 % |
| Degree of pollution | 2 |
| Installation height | 2000 m |
Input data
| Nominal input voltage | 24 V DC |
|---|---|
| Input voltage range | 18 V DC … 30 V DC |
| Current consumption | 5 A |
| Buffer period | 12 min. (1 A) |
| 33 s (20 A) |
Output data
| Nominal output voltage | 24 V DC |
|---|---|
| Setting range of the output voltage (USet) | 22 V DC … 27 V DC |
| Nominal output current (IN) | 20 A |
| POWER BOOST (IBoost) | 26 A |
| Connection in series | No |
| Power loss nominal load max. | 3.6 W |
| Output fuse | 2x 25 A (internal) |
General
| IQ technology | Yes |
|---|---|
| Disposal | Used batteries must not be thrown away with household waste, they should instead be disposed of in accordance with applicable national regulations. They can also be returned to Phoenix Contact or the manufacturer. |
| Net weight | 2.9 kg |
| Memory medium | Dual layer capacitor |
| Protection class | III |
| Degree of protection | IP20 |
| MTBF (IEC 61709, SN 29500) | |
| > 695000 h (40 °C) | |
| Mounting position | horizontal DIN rail NS 35, EN 60715 |
