Key Commercial Data
| Orderkey | 2976158 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 579 (C-5-2017) |
| GTIN | 4017918089221 |
| Weight per Piece (excluding packing) | 4.220 g |
| Custom tariff number | 85369010 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
General
| Max. perm. operating voltage | 25 V AC |
|---|---|
| 60 V DC | |
| Max. perm. current (per branch) | 1.5 A |
| Max. permissible current (all branches) | 28 A (56 branches with 0.5 A each) |
| Number of positions | 56 |
| Mounting position | any |
| Degree of protection | IP00 |
Connection data for connection 1
| Connection name | Field level |
|---|---|
| Connection in acc. with standard | IEC / EN |
| Connection method | Screw connection |
| Stripping length | 9 mm |
| Screw thread | M2,5 |
| Conductor cross section solid | 0.2 mm² … 2.5 mm² |
| Conductor cross section flexible | 0.2 mm² … 1.5 mm² |
| Conductor cross section AWG | 26 … 16 |
Connection data for connection 2
| Connection name | Controller level |
|---|---|
| Connection method | ELCO connector |
| Coding | 4-4 |
| Number of connections | 1 |
| Number of positions | 56 |
| Note | Pin strip type 8016, left |
