Key Commercial Data
| Orderkey | 2900892 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 565 (C-7-2015) |
| GTIN | 4046356545112 |
| Weight per Piece (excluding packing) | 434.800 g |
| Custom tariff number | 85369010 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Input data
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range in reference to UN | 0.9 … 1.1 |
| Typical input current at UN | 17 mA |
| Typical response time | 8 ms |
| Typical release time | 10 ms |
| Type of protection | Free-wheeling diode |
| Operating voltage display | Green LED |
| Status display/channel | Yellow LED |
Output data
| Contact type | 1 PDT |
|---|---|
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC/DC |
| Minimum switching voltage | 12 V AC/DC |
| Limiting continuous current | 3.9 A (observe derating) |
| Min. switching current | 10 mA |
| Interrupting rating (ohmic load) max. | 93 W (24 V DC) |
| 58 W (48 V DC) | |
| 48 W (60 V DC) | |
| 50 W (110 V DC) | |
| 80 W (220 V DC) | |
| 975 VA (250 V AC) | |
| Output fuse | 4 A 5×20 fuse (slow-blow) |
| Fuse | 5×20 fuse |
