Key Commercial Data
| Orderkey | 2319430 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4046356550031 |
| Weight per Piece (excluding packing) | 1,516.000 g |
| Custom tariff number | 85369010 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Input data
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range in reference to UN | 0.9 … 1.1 |
| Typical input current at UN | 40 mA |
| Protective circuit/component | Damping diode |
| Status display/channel | Yellow LED |
Output data
| Contact type | 1 N/O contact per channel |
|---|---|
| Contact material | AgNi (90/10) gold-plated |
| Maximum switching voltage | 230 V AC/DC |
| Limiting continuous current | 4 A (plug-in fuse) |
| Maximum inrush current | Supply 24 V DC/2 A, (P1+, P2+), pluggable fuse (IEC 60127-3/IV, 2AT) |
