Key Commercial Data
| Orderkey | 2900175 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 523 (C-5-2017) |
| GTIN | 4046356484039 |
| Weight per Piece (excluding packing) | 583.400 g |
| Custom tariff number | 85369010 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
General
| Note | Voltage monitoring on the module does not work in combination with upstream HESILED fuse terminal blocks with integrated LED display. |
|---|---|
| Max. perm. operating voltage | 24 V DC ±5 % |
| Max. perm. current (per branch) | 100 mA |
| Max. permissible current (separate power supply) | 6.3 AT (F150, F151) plug-in fuse (5×20, 6.3 A), DIN 41662 |
| Number of positions | 50 |
| Status display | Green LED (supply), yellow LED (channel) |
| Mounting position | any |
| Degree of protection | IP00 |
Connection data for connection 1
| Connection name | Field level |
|---|---|
| Connection method | Screw connection |
| Conductor cross section solid | 0.2 mm² … 2.5 mm² |
| Conductor cross section flexible | 0.2 mm² … 1.5 mm² |
| Conductor cross section AWG | 24 … 14 |
| Number of positions | 32 |
