Key Commercial Data
| Orderkey | 2794770 |
|---|---|
| Packing unit | 50 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4017918072940 |
| Weight per Piece (excluding packing) | 11.140 g |
| Custom tariff number | 85363030 |
| Country of origin | GR (Greece) |
General
| Housing material | PA |
|---|---|
| Flammability rating according to UL 94 | V-2 |
| Type | Single-level terminal block |
| Direction of action | Line-Earth Ground |
Protective circuit
| Nominal voltage UN | 110 V AC |
|---|---|
| Maximum continuous voltage UC | 121 V AC |
| Rated current | 32 A (50 °C) |
| Residual current IPE | ≤ 5 µA |
| Nominal discharge current In(8/20) µs (line-earth) | 51 A |
| Nominal pulse current Ian (10/1000) µs (line-earth) | 5.5 A |
| Capacity (line-earth) | ≤ 0.34 nF |
| Surge protection fault message | none |
Connection data
| Connection method | Screw terminal blocks |
|---|---|
| Screw thread | M3 |
| Tightening torque | 0.8 Nm |
| Stripping length | 8 mm |
| Conductor cross section flexible | 0.2 mm² … 4 mm² |
| Conductor cross section solid | 0.2 mm² … 4 mm² |
| Conductor cross section AWG | 24 … 12 |
