Dimensions
| External dimension, width | 140 mm |
|---|---|
| External dimension, height | 100 mm |
| External dimension, depth | 5 mm |
| Note regarding external dimension | Dimensions of the front plate |
| Installation dimension, width | 132 mm |
| Installation dimension, height | 92 mm |
| Note regarding installation dimension | Installation cutout |
| Installation dimension, depth | 42 mm |
Display
| Display | 10,92 cm / 4,3″-TFT |
|---|---|
| Brightness | 385 cd/m² typical (adjustable) |
| Screen resolution | 480 x 272 Pixel(s) (WQVGA) |
| Backlighting | LED |
| Display backlight MTBF | 40000 h |
| Touch technology | analog resistive (polyester) |
| Colors | 262144 colors |
| Reading angle left | 75 ° |
| Reading angle right | 75 ° |
| Reading angle top | 63 ° |
| Reading angle bottom | 75 ° |
Computer data
| Processor | Arm® Cortex®-A8, 800 MHz |
|---|---|
| Operating system | Windows® Embedded Compact 7 |
| User software | Movicon™ |
| RAM | 512 MB LPDDR SDRAM |
| Mass storage | NAND-Flash, 256 MB |
| Network | 1 x Ethernet (10/100 Mbps), RJ45 |
| Interfaces | 2x USB host 2.0 |
| Bus system | without |
| Slots | 1x SD |
| Realtime clock | Yes (battery-backed) |
| Service life of battery | 5 years (typical) |
General
| Material front plate | Aluminum (natural anodized) |
|---|---|
| Housing material | Steel sheet, zinc-plated |
| Mounting type | Front installation |
| Weight | 600 g |
