Key Commercial Data
| Orderkey | 2403862 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 23 (C-6-2017) |
| GTIN | 4055626363578 |
| Weight per Piece (excluding packing) | 99.990 g |
| Custom tariff number | 84714100 |
| Country of origin | DE (Germany) |
Dimensions
| Outer dimensions: width, height, depth | 485 mm x 329 mm x 6 mm (Dimensions of the front plate) |
|---|---|
| Installation dimensions: width, height, depth | 475 mm x 311 mm x 53 mm (Installation cutout) |
Display
| Display | 47.0 cm / 18.5″ TFT |
|---|---|
| Brightness | 240 cd/m², typical (adjustable) |
| Screen resolution | 1366 x 768 Pixel(s) (WXGA) |
| Backlighting | LED |
| Display backlight MTBF | 50000 h |
| Touch technology | Projective-capacitive (PCAP) |
| Colors | 65536 colors |
| Reading angle left | 85 ° |
| Reading angle right | 85 ° |
| Reading angle top | 80 ° |
| Reading angle bottom | 80 ° |
Computer data
| Processor | Arm®Cortex®-A8, 1000 MHz |
|---|---|
| Operating system | Windows®Embedded Compact 7 |
| User software | Visu+ |
| RAM | 512 MB LPDDR RAM |
| Mass storage | NAND-Flash, 1 GB |
| Network | 1 x Ethernet (10/100 Mbps), RJ45 |
| Interfaces | 2x USB host 2.0 |
| Bus system | without |
| Slots | 1x SD |
| Realtime clock | Yes (battery-backed) |
| Service life of battery | 5 years (typical) |
General
| Material front plate | Aluminum (natural anodized) |
|---|---|
| Housing material | Steel sheet, zinc-plated |
| Mounting type | Front installation |
| Weight | 5600 g |
