Key Commercial Data
| Orderkey | 0915797 |
|---|---|
| Packing unit | 6 pc |
| Catalog page | Page 281 (CL-2002) |
| GTIN | 4017918600631 |
| Weight per Piece (excluding packing) | 46.160 g |
| Custom tariff number | 85362010 |
| Country of origin | DE (Germany) |
General
| Mounting type | on base element |
|---|---|
| Color | black |
| Number of positions | 1 |
| Overvoltage category_GRP | II |
| Insulating material | PA66 |
| Flammability rating according to UL 94 | V-2 |
Electrical data
| Fuse type | Automatic device |
|---|---|
| Rated surge voltage | 2.5 kV |
| Rated voltage | 250 V AC |
| 65 V DC | |
| Rated current IN | 4 A |
| Insulation resistance Riso | > 100 MΩ (500 V DC) |
| Rated short-circuit switching capacity Icn | 400 A |
| 2500 A (32 V DC) | |
| Short-circuit switching capacity Ik | 5000 A (UL 1077: 277 V AC) |
| 2000 A (UL 1077: 65 V DC) | |
| Dielectric strength | 3000 V AC (Actuation area) |
| 1500 V AC (Main to auxiliary circuit) | |
| 1000 V AC (Auxiliary circuit 11 – 12 to 23 – 24) | |
| Switching cycles, max. | 10000 (At 1 x In, inductive) |
| Degree of pollution | 2 |
| Overvoltage category_GRP | II |
| Insulating material group | II |
Dimensions
| Height | 50 mm |
|---|---|
| Width | 12.5 mm |
| Depth | 78.5 mm |
| Complete module height | 115 mm |
| Complete module width | 38 mm |
| Complete module depth | 121 mm |
Ambient conditions
| Degree of protection | IP30 (Actuation area) |
|---|---|
| IP00 (Connection area) | |
| Ambient temperature (operation) | -30 °C … 60 °C |
