Key Commercial Data
| Orderkey | 0712291 |
|---|---|
| Packing unit | 20 pc |
| Catalog page | Page 335 (C-4-2017) |
| GTIN | 4017918848408 |
| Weight per Piece (excluding packing) | 10.630 g |
| Custom tariff number | 85362010 |
| Country of origin | ID (Indonesia) |
General
| Installation instructions | When mounted in rows, the nominal device current can be limited to just 80% or must be overdimensioned accordingly. |
|---|---|
| Mounting type | on base element |
| Color | black |
| Number of positions | 1 |
| Overvoltage category_GRP | II |
| Insulating material | PPS |
| Flammability rating according to UL 94 | V0 |
Electrical data
| Fuse | Slow-blow |
|---|---|
| Fuse type | Automatic device |
| Rated surge voltage | 2.5 kV |
| Rated voltage | 250 V AC |
| 65 V DC | |
| 250 V (AC according to UL 1077) | |
| 72 V (DC according to UL 1077) | |
| Rated current IN | 8 A |
| Insulation resistance Riso | > 100 MΩ (500 V DC) |
| Rated short-circuit switching capacity Icn | 64 A (250 V AC / 65 V DC) |
| 160 A (30 V DC) | |
| Short-circuit switching capacity Ik | 2000 A (250 V AC / UL 1077) |
| 2000 A (72 V DC / UL 1077) | |
| Dielectric strength | 3000 V AC (Actuation area) |
| 1500 V AC (Installation area) | |
| Switching cycles, max. | 6000 (At 1 x In, low-induction) |
| 3000 (At 1 x In, inductive) | |
| 500 (At 2 x In, inductive) | |
| Degree of pollution | 2 |
| Overvoltage category_GRP | II |
| Insulating material group | IIIb |
Ambient conditions
| Degree of protection | IP40 (Actuation area) |
|---|---|
| Ambient temperature (operation) | -20 °C … 60 °C |
