Key Commercial Data
| Orderkey | 2903588 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 351 (C-6-2017) |
| GTIN | 4046356758109 |
| Weight per Piece (excluding packing) | 649.700 g |
| Custom tariff number | 85176200 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -40 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 70 °C |
| Permissible humidity (operation) | 5 % … 95 % (non-condensing) |
| Altitude | 5000 m (For restrictions see manufacturer’s declaration) |
| Degree of protection | IP20 |
General
| Electrical isolation | VCC // PE |
|---|---|
| Test voltage data interface/data interface | 1 kV (50 Hz, 1 min.) |
| Test voltage data interface/power supply | 1 kV (50 Hz, 1 min.) |
| Electromagnetic compatibility | Conformance with RED Directive 2014/53/EU |
| Net weight | 649.7 g |
| Housing material | Metal |
| Color | silver |
| MTTF | 582 Years (SN 29500 standard, temperature 25 °C, operating cycle 21 % (5 days a week, 8 hours a day)) |
| 271 Years (SN 29500 standard, temperature 40 °C, operating cycle 34.25 % (5 days a week, 12 hours a day)) | |
| 114 Years (SN 29500 standard, temperature 40 °C, operating cycle 100 % (7 days a week, 24 hours a day)) | |
| Degree of pollution | 2 |
| Conformance | CE-compliant |
| Wireless licences | Europe |
Power supply
| Supply voltage range | 11 V DC … 36 V DC (via pluggable COMBICON screw terminal block) |
|---|---|
| Max. current consumption | < 1.8 A (at 11 V DC (incl. 3 x 125 mA for the outputs)) |
| Typical current consumption | < 320 mA (24 V DC) |
| Conductor cross section solid max. | 2.50 mm² |
| Conductor cross section solid min. | 0.20 mm² |
| Max. AWG conductor cross section, flexible | 14 |
| Min. AWG conductor cross section, flexible | 24 |
