Key Commercial Data
| Orderkey | 2702253 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 361 (C-6-2017) |
| GTIN | 4055626055558 |
| Weight per Piece (excluding packing) | 258.700 g |
| Custom tariff number | 85176200 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -25 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Permissible humidity (operation) | 10 % … 95 % (non-condensing) |
| Permissible humidity (storage/transport) | 10 % … 95 % (non-condensing) |
| Altitude | 2500 m (For restrictions see manufacturer’s declaration) |
| Degree of protection | IP20 |
General
| Electrical isolation | VCC // Ethernet // DSL (A/B) // FE |
|---|---|
| Test voltage data interface/power supply | 1.5 kV AC (50 Hz, 1 min.) |
| Electromagnetic compatibility | Conformance with EMC Directive 2014/30/EU |
| Net weight | 258.7 g |
| Housing material | Aluminum / steel sheet DC01 |
| MTTF | 577 Years (SN 29500 standard, temperature 25 °C, operating cycle 21 % (5 days a week, 8 hours a day)) |
| 300 Years (SN 29500 standard, temperature 40 °C, operating cycle 34.25 % (5 days a week, 12 hours a day)) | |
| 128 Years (SN 29500 standard, temperature 40 °C, operating cycle 100 % (7 days a week, 24 hours a day)) | |
| Conformance | CE-compliant |
| ATEX | II 3 G Ex nA IIC T4 Gc X (Please follow the special installation instructions in the documentation!) |
| UL, USA/Canada | 508 Listed |
Power supply
| Nominal supply voltage | 24 V DC ±5 % |
|---|---|
| Supply voltage range | 10 V DC … 60 V DC |
| Typical current consumption | 80 mA (60 V DC) |
| 200 mA (24 V DC) | |
| 380 mA (10 V DC) | |
| Connection method | Push-in spring connection |
