Key Commercial Data
| Orderkey | 2902326 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 373 (C-6-2017) |
| GTIN | 4046356655019 |
| Weight per Piece (excluding packing) | 62.600 g |
| Custom tariff number | 85366990 |
| Country of origin | CN (China) |
Ambient conditions
| Ambient temperature (operation) | -30 °C … 80 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Ambient temperature (assembly) | -20 °C … 80 °C |
| Permissible humidity (operation) | 10 % … 75 % (At +25°C, non-condensing) |
| Altitude | 5000 m (For restrictions see manufacturer’s declaration) |
| Degree of protection | IP40 |
General
| Bus system | CAN, CANopen, SafetyBus-P |
|---|---|
| Signal | CAN |
| CANopen® | |
| SUBCON fixing screws | 4-40 UNC |
| Tightening torque | 0.4 Nm |
| Housing material | Polyamide |
| Pin assignment | 2, 3, 5, 7, 9 |
| MTTF | 6706 Years (SN 29500 standard, temperature 25 °C, operating cycle 21 % (5 days a week, 8 hours a day)) |
| 1817 Years (SN 29500 standard, temperature 40 °C, operating cycle 34.25 % (5 days a week, 12 hours a day)) | |
| 155 Years (SN 29500 standard, temperature 40 °C, operating cycle 100 % (7 days a week, 24 hours a day)) |
Connection data
| Connection | D-SUB connection |
|---|---|
| Number of positions | 9 |
| Connection method | D-SUB socket |
| Termination resistor | separately via M12 termination resistor |
| Connection | M12 plug |
| Number of positions | 5 |
| Connection method | M12 connector, A-coded |
| Torque | 0.4 Nm |
| Connection | M12 socket |
| Number of positions | 5 |
| Connection method | M12 connector, A-coded |
| Torque | 0.4 Nm |
