Key Commercial Data
| Orderkey | 2868606 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 267 (C-4-2017) |
| GTIN | 4046356583923 |
| Weight per Piece (excluding packing) | 73.200 g |
| Custom tariff number | 85049091 |
| Country of origin | PL (Poland) |
Ambient conditions
| Degree of protection | IP20 |
|---|---|
| Ambient temperature (operation) | -25 °C … 70 °C (> 55° C derating : 2.5%/K) |
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Max. permissible relative humidity (operation) | ≤ 95 % (at 25 °C, non-condensing) |
| Climatic class | 3K3 (in acc. with EN 60721) |
| Degree of pollution | 2 |
Input data
| Nominal input voltage range | 5 V DC … 24 V DC |
|---|---|
| 5 V DC … 24 V DC | |
| Input voltage range | 4.5 V DC … 30 V DC |
| Nominal input current | 2x 5 A (-25 °C … 55 °C) |
| 1x 10 A (-25 °C … 55 °C) | |
| 2x 5 A (-25 °C … 55 °C) | |
| 1x 10 A (-25 °C … 55 °C) |
Output data
| Nominal output voltage | 24 V DC |
|---|---|
| Setting range of the output voltage (USet) | 5 V DC … 24 V DC |
| Nominal output current (IN) | 10 A (Increasing power) |
| 5 A (Redundancy) | |
| Derating | 55 °C … 70 °C (2.5%/K) |
| Connection in series | No |
| Power loss nominal load max. | 2.5 W (IOUT= 5 A) |
General
| Net weight | 0.1 kg |
|---|---|
| Efficiency | > 97 % |
| > 97 % | |
| Protection class | III |
| Degree of protection | IP20 |
| MTBF (IEC 61709, SN 29500) | |
| > 25822000 h (40 °C) | |
| Mounting position | horizontal DIN rail NS 35, EN 60715 |
| Assembly instructions | alignable: 0 mm horizontally, 30 mm vertically |
