Ambient conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Coil side
| Nominal input voltage UN | 120 V AC/DC |
|---|---|
| Input voltage range in reference to UN | 0.85 … 1.06 |
| Typical input current at UN | 4 mA |
| Typical response time | 10 ms |
| Typical release time | 10 ms |
| Protective circuit | Bridge rectifier Bridge rectifier |
| Surge protection Varistor | |
| Operating voltage display | Yellow LED |
| Power dissipation for nominal condition | 0.48 W |
Contact side
| Contact type | Single contact, 2 N/O contact |
|---|---|
| Type of switch contact | Single contact |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC/DC |
| Maximum inrush current | 6 A |
| Limiting continuous current | 5 A |
| Interrupting rating (ohmic load) max. | 120 W (at 24 V DC) |
| 85 W (at 48 V DC) | |
| 60 W (at 60 V DC) | |
| 40 W (at 110 V DC) | |
| 60 W (at 220 V DC) | |
| 1250 VA (for 250 V AC) |
General
| Test voltage relay winding/relay contact | 2.5 kV AC (50 Hz, 1 min.) |
|---|---|
| Test voltage relay contact/relay contact | 2 kV AC (50 Hz, 1 min.) |
| Operating mode | 100% operating factor |
| Mechanical service life | approx. 5x 107 cycles |
| Net weight (SAP) | 40 g |
