Ambient conditions
| Ambient temperature (operation) | -20 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Coil side
| Nominal input voltage UN | 120 V AC |
|---|---|
| Input voltage range in reference to UN | 0.8 … 1.1 |
| Typical input current at UN | 13 mA |
| Typical response time | 4 ms … 15 ms (with AC) |
| Typical release time range | 4 ms … 15 ms (with AC) |
| Operating voltage display | yes |
| Power dissipation for nominal condition | 1.56 W |
Contact side
| Contact type | Single contact, 1-PDT |
|---|---|
| Type of switch contact | Single contact |
| Contact material | Ag, gold-flashed |
| Maximum switching voltage | 250 V AC/DC |
| Maximum inrush current | 5 A |
| Limiting continuous current | 5 A |
| Interrupting rating (ohmic load) max. | 120 W (at 24 V DC) |
| 60 W (at 48 V DC) | |
| 50 W (at 60 V DC) | |
| 50 W (at 110 V DC) | |
| 70 W (at 220 V DC) | |
| 500 VA (for 250 V AC) |
General
| Test voltage relay winding/relay contact | 1 kV AC (50 Hz, 1 min.) |
|---|---|
| Operating mode | 100% operating factor |
| Mechanical service life | approx. 107 cycles (approx. 106 with AC relay) |
| Net weight (SAP) | 55.8 g |
