Ambient conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Coil side
| Nominal input voltage UN | 24 V AC |
|---|---|
| Input voltage range in reference to UN | 0.9 … 1.1 |
| Typical input current at UN | 26 mA |
| Typical response time | 8 ms (with DC) |
| Typical release time | 10 ms (with DC) |
| Protective circuit | Bridge rectifier Bridge rectifier |
| Surge protection Varistor | |
| RC element RC element | |
| Operating voltage display | Yellow LED |
| Power dissipation for nominal condition | 0.62 W |
Contact side
| Contact type | Double contact, 1 PDT |
|---|---|
| Type of switch contact | Double contact |
| Contact material | Au |
| Maximum switching voltage | 30 V AC |
| 36 V DC | |
| Maximum inrush current | 0.2 A |
| Limiting continuous current | 0.5 A |
| Interrupting rating (ohmic load) max. | 5 W |
General
| Test voltage relay winding/relay contact | 2.5 kV AC (50 Hz, 1 min.) |
|---|---|
| Mechanical service life | approx. 2x 107 cycles |
| Mounting position | any |
| Net weight (SAP) | 41 g |
