Key Commercial Data
| Orderkey | 2826486 |
|---|---|
| Packing unit | 10 pc |
| Catalog page | Page 87 (IF-2005) |
| GTIN | 4017918077952 |
| Weight per Piece (excluding packing) | 35.400 g |
| Custom tariff number | 85364900 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Coil side
| Nominal input voltage UN | 230 V AC |
|---|---|
| Input voltage range in reference to UN | 0.8 … 1.06 |
| Mains frequency | 50/60 Hz |
| Typical input current at UN | 5 mA |
| Typical response time | 4 ms … 10 ms (with AC) |
| Typical release time range | 4 ms … 10 ms (with AC) |
| Protective circuit | Bridge rectifier Bridge rectifier |
| Surge protection Varistor | |
| Operating voltage display | yes |
| Power dissipation for nominal condition | 1.15 W |
Contact side
| Contact type | Double contact, 1 N/O contact |
|---|---|
| Type of switch contact | Double contact |
| Contact material | AgPd60, hard gold-plated |
| Maximum switching voltage | 30 V AC |
| 36 V DC | |
| Maximum inrush current | 0.2 A |
| Limiting continuous current | 0.5 A |
| Interrupting rating (ohmic load) max. | 5 W (at 24 V DC) |
General
| Test voltage relay winding/relay contact | 2.5 kV AC (50 Hz, 1 min.) |
|---|---|
| Operating mode | 100% operating factor |
| Mechanical service life | approx. 2x 107cycles |
| Net weight (SAP) | 35.4 g |
