Key Commercial Data
| Orderkey | 2826512 |
|---|---|
| Packing unit | 10 pc |
| Catalog page | Page 87 (IF-2005) |
| GTIN | 4017918077983 |
| Weight per Piece (excluding packing) | 32.500 g |
| Custom tariff number | 85364900 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -20 °C … 40 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Coil side
| Nominal input voltage UN | 220 V DC |
|---|---|
| Input voltage range in reference to UN | 0.8 … 1.06 |
| Typical input current at UN | 4.5 mA |
| Typical response time | 6 ms (with DC) |
| Typical release time | 11 ms (with DC) |
| Protective circuit | Damping diode, polarity protection Damping diode, polarity protection diode, varistor |
| Operating voltage display | yes |
| Power dissipation for nominal condition | 0.99 W |
Contact side
| Contact type | Single contact, 1 N/O contact |
|---|---|
| Type of switch contact | Single contact |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC/DC |
| Maximum inrush current | 8 A |
| Limiting continuous current | 6 A |
| Interrupting rating (ohmic load) max. | 95 W (at 24 V DC) |
| 50 W (at 48 V DC) | |
| 45 W (at 60 V DC) | |
| 45 W (at 110 V DC) | |
| 75 W (at 220 V DC) | |
| 1500 VA (for 250 V AC) |
General
| Test voltage relay winding/relay contact | 2.5 kV AC (50 Hz, 1 min.) |
|---|---|
| Operating mode | 100% operating factor |
| Mechanical service life | approx. 2x 107cycles |
| Assembly instructions | After every 5 modules, spacing of 10 mm |
| Net weight (SAP) | 32.5 g |
