Key Commercial Data
| Orderkey | 1640799 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 64 (PC-2002) |
| GTIN | 4017918180959 |
| Weight per Piece (excluding packing) | 35.820 g |
| Custom tariff number | 85366990 |
| Country of origin | DE (Germany) |
General
| Rated current at 40°C | 2 A |
|---|---|
| Rated voltage | 30 V DC |
| Number of positions | 4 |
| Coding | A – standard |
| Status display | LED red |
| Protective circuit/component | Power amplifier with zener diode |
| Overvoltage category | II |
| Degree of pollution | 3 |
| Connection method | QUICKON |
| Conductor cross section | 0.34 mm² … 0.75 mm² |
| Wire diameter incl. insulation | ≤ 2.5 mm |
| Frequency of connections between conductors of the same cross section | 10 (if the conductor is connected more than once, seal and cap may need to be replaced) |
| Wire insulation material | PVC / PE |
| Tightening torque, union nut | 2.5 Nm |
| Structure of individual litz in acc. with VDE 0295 / smallest wire diameter | Class 2-5 |
Material
| Flammability rating according to UL 94 | HB |
|---|---|
| Contact material | CuSn |
| Contact surface material | Ag |
