Key Commercial Data
| Orderkey | 1528002 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 79 (PC-2005) |
| GTIN | 4017918981075 |
| Weight per Piece (excluding packing) | 21.700 g |
| Custom tariff number | 85366990 |
| Country of origin | HU (Hungary) |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 85 °C (valve plug) |
|---|---|
| Degree of protection | IP65 |
General
| Rated current at 40°C | 10 A |
|---|---|
| Rated voltage | 24 V |
| Number of positions | 3 |
| Insulation resistance | ≥ 100 MΩ |
| Status display | 1 LED |
| Protective circuit/component | Varistor |
| Overvoltage category | II |
| Degree of pollution | 3 |
| Connection method | Screw connection |
| Conductor cross section | 0.34 mm² … 1.5 mm² |
| Conductor cross section AWG | 22 … 16 |
| Insertion/withdrawal cycles | 50 (Valve connector) |
Material
| Flammability rating according to UL 94 | HB |
|---|---|
| Valve plug contact material | CuZn |
| Valve plug contact surface material | Ni |
| Valve plug contact insert material | PA6 |
| Material housing valve plug | PA6 |
| Sealing material | NBR |
