Key Commercial Data
| Orderkey | 1411046 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 185 (NTK-2014) |
| GTIN | 4046356920216 |
| Weight per Piece (excluding packing) | 22.220 g |
| Custom tariff number | 85366990 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 85 °C (Plug / socket) |
|---|---|
| Degree of protection | IP67 |
General
| Note | Order crimp contacts separately |
|---|---|
| This product corresponds to the PROFINET Cabling and Interconnection Technology Guideline for PROFINET regulations, version 2.00, order no: 2.252, Chapter 8.2 Connectors for Outside Environment (Balanced cabling) | |
| Rated current at 40°C | 4 A |
| Rated voltage | 60 V DC |
| 48 V AC | |
| Number of positions | 4 |
| Insulation resistance | ≥ 10 GΩ |
| Coding | D – data |
| Standards/regulations | M12 connector IEC 61076-2-101 |
| Signal type/category | PROFINET CAT5 (on the basis of IEC 11801) |
| Status display | No |
| Overvoltage category | II |
| Degree of pollution | 3 |
| Connection method | Crimp connection |
| Conductor cross section | 0.34 mm² … 0.5 mm² |
| Conductor cross section AWG | 22 … 20 |
| Insertion/withdrawal cycles | ≥ 100 |
| Torque | 0.6 Nm (M12 knurl) |
| 1 Nm (Connector with coupling sleeve) | |
| 1 Nm (Pressure nut with coupling sleeve) |
Material
| Flammability rating according to UL 94 | HB |
|---|---|
| Contact carrier material | PA |
| Material of grip body | Zinc die-cast, nickel-plated |
| Material, knurls | Zinc die-cast, nickel-plated |
| Sealing material | FPM (O-ring) |
| NBR (Cable clamping) |
Standards and Regulations
| Standard designation | M12 connector |
|---|---|
| Standards/regulations | IEC 61076-2-101 |
| Flammability rating according to UL 94 | HB |
