Key Commercial Data
| Orderkey | 1506781 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 257 (C-8-2015) |
| GTIN | 4017918892708 |
| Weight per Piece (excluding packing) | 19.400 g |
| Custom tariff number | 85366990 |
| Country of origin | DE (Germany) |
Dimensions
| Wrench size, union nut | 11 mm |
|---|---|
| Diameter housing | 12 mm |
| Length | 33.9 mm |
| External cable diameter | 3 mm … 5 mm |
| Stripping length of the sheath | 35 mm |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 85 °C (Plug / socket) |
|---|---|
| Degree of protection | IP68 |
General
| Rated current at 40°C | 4 A |
|---|---|
| Rated voltage | 30 V AC |
| 30 V DC | |
| Number of positions | 4 |
| Insulation resistance | ≥ 100 MΩ |
| Coding | A – standard |
| Standards/regulations | M8 connector IEC 61076-2-104 |
| Status display | No |
| Overvoltage category | II |
| Degree of pollution | 3 |
| Connection method | Piercecon®fast connection |
| Conductor cross section | 0.14 mm² … 0.38 mm² (flexible) |
| Conductor cross section AWG | 22 … 26 (flexible) |
| Wire diameter including insulation | 1 mm … 1.3 mm (Black wire clamping for 0.14 mm² … 0.25 mm²) |
| 1.3 mm … 1.6 mm (White wire clamping for 0.25 mm² … 0.38 mm²) | |
| Insertion/withdrawal cycles | ≥ 100 |
| Torque | 0.5 Nm (Pressure nut with coupling sleeve) |
| 0.8 Nm (Connector with coupling sleeve) | |
| 0.2 Nm (M8 knurl) |
Material
| Flammability rating according to UL 94 | V0 |
|---|---|
| Contact material | CuZn |
| Contact surface material | Ni/Au |
| Contact carrier material | PA 6.6 |
| Material of grip body | PA 6.6 |
| Material, knurls | Nickel-plated brass |
| Sealing material | NBR |
Standards and Regulations
| Standard designation | M8 connector |
|---|---|
| Standards/regulations | IEC 61076-2-104 |
| Flammability rating according to UL 94 | V0 |
