Key Commercial Data
| Orderkey | 1521452 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 49 (C-4-2015) |
| GTIN | 4017918949679 |
| Weight per Piece (excluding packing) | 52.100 g |
| Custom tariff number | 85366990 |
| Country of origin | DE (Germany) |
General
| Rated current at 40°C | 9 A |
|---|---|
| Rated voltage | 250 V |
| Number of positions | 5 |
| Insulation resistance | ≥ 100 MΩ |
| Coding | A – standard |
| Status display | No |
| Overvoltage category | II |
| Degree of pollution | 3 |
| Connection method | Individual wires |
| Mounting type | Front mounting Pg13.5 |
Material
| Flammability rating according to UL 94 | HB |
|---|---|
| Contact material | CuZn |
| Contact surface material | Au |
| Contact carrier material | PUR |
| Material, knurls | Zinc die-cast, nickel-plated |
| Sealing material | Viton |
Cable
| Cable type | PVC litz wire |
|---|---|
| Conductor cross section | 0.75 mm² |
| AWG signal line | 18 |
| Conductor structure signal line | 24x 0.20 mm |
| Core diameter including insulation | 2.7 mm |
| Thickness, insulation | 0.85 mm (Core insulation) |
| Wire colors | brown, white, blue, black, green-yellow |
| Material conductor insulation | PE |
