SACC-DSI-M12FS-5CON-PG9-L180 1409463 PHOENIX CONTACT Sensor/actuator flush-type male connector, 5-pos., M12 ..

SACC-DSI-M12FS-5CON-PG9-L180 1409463 PHOENIX CONTACT Sensor/actuator flush-type male connector, 5-pos., M12 ..

SACC-DSI-M12FS-5CON-PG9-L180 1409463 PHOENIX CONTACT Sensor/actuator flush-type male connector, 5-pos., M12 ..

Sensor/actuator flush-type male connector, 5-pos., M12 standard thread, A-coded, rear/screw mounting with Pg9 thread, with straight solder connection

sản phẩm chính hãng, MỚI 100% CHƯA SỬ DỤNG
SẢN PHẨM LUÔN ĐƯỢC KIỂM TRA TRƯỚC KHI XUẤT KHO
BẢO HÀNH 12 THÁNG ĐỐI VỚI LỖI CỦA NHÀ SẢN XUẤT / HOẶC THEO CHÍNH SÁCH CỦA SẢN PHẨM DO TRƯỜNG THỊNH PHÂN PHỐI
HỖ TRỢ KỸ THUẬT 24/7
MIỄN PHÍ GIAO HÀNG ĐỐI VỚI CÁC ĐƠN HÀNG TỪ 8,000,000VNĐ

Liên hệ:

SKU: 1409463 Danh mục: Field Device Connectors (FDC) Thẻ: 1409463, PHOENIX_CONTACT, SACC-DSI-M12FS-5CON-PG9-L180

Mô tả

Key Commercial Data

Orderkey	1409463
Packing unit	1 pc
Minimum order quantity	200 pc
GTIN	4046356893558
Weight per Piece (excluding packing)	14.000 g
Custom tariff number	85366990
Country of origin	DE (Germany)

Drawings
Material
Standards and Regulations
Classifications

General
Cable
Environmental Product Compliance

Drawings


Drilling diagram		Dimensional drawing M12 flush-type connector

Dimensional drawing Housing cutout for Pg9 fastening thread, mounting panel with feed-through hole (alternatively with area as anti-rotation protection for panel thicknesses > 2 mm up to max. 4.5 mm)		Dimensional drawing M12 front view

Schematic diagram Pin assignment M12 socket, 5-pos., A-coded, socket side view

General

Note	The electrical and mechanical data specified assume that the connector pair is correctly locked and mounted. If the connector is unlocked and if there is a danger of contamination, the connector must be sealed using a protective cap > IP54. Influences arising from litz wires, cables or PCB assembly must also be taken into consideration.
Rated current at 40°C	4 A
Rated voltage	60 V
Number of positions	5
Standards/regulations	M12 connector IEC 61076-2-101
Overvoltage category	II
Degree of pollution	3

Material

Flammability rating according to UL 94	V0

Cable

Standards/specifications	M12 connector IEC 61076-2-101

Standards and Regulations

Standards/specifications	M12 connector IEC 61076-2-101
Flammability rating according to UL 94	V0

Environmental Product Compliance

REACh SVHC
	Lead 7439-92-1
China RoHS	Environmentally Friendly Use Period = 50
	For details about hazardous substances go to tab “Downloads”, Category “Manufacturer’s declaration”

Classifications

[email protected]

[email protected] 10.0.1	27440102
[email protected] 5.1	27143423
[email protected] 6.0	27279220
[email protected] 8.0	27440103
[email protected] 9.0	27440102

ETIM

ETIM 5.0	EC002062
ETIM 6.0	EC002062

UNSPSC

UNSPSC 13.2	39121413
UNSPSC 18.0	39121413
UNSPSC 19.0	39121413
UNSPSC 20.0	39121413
UNSPSC 21.0	39121413

Drawings
Material
Standards and Regulations
Classifications

General
Cable
Environmental Product Compliance

Drawings


Drilling diagram		Dimensional drawing M12 flush-type connector

Dimensional drawing Housing cutout for Pg9 fastening thread, mounting panel with feed-through hole (alternatively with area as anti-rotation protection for panel thicknesses > 2 mm up to max. 4.5 mm)		Dimensional drawing M12 front view

Schematic diagram Pin assignment M12 socket, 5-pos., A-coded, socket side view

Material

Flammability rating according to UL 94	V0
