Key Commercial Data
| Orderkey | 1453478 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 32 (C-2-2017) |
| GTIN | 4046356554381 |
| Weight per Piece (excluding packing) | 10.600 g |
| Custom tariff number | 85444290 |
| Country of origin | DE (Germany) |
General
| Rated current at 40°C | 4 A |
|---|---|
| Rated voltage | 50 V AC |
| 60 V DC | |
| Rated surge voltage | 1.5 kV |
| Number of positions | 3 |
| Insulation resistance | ≥ 100 MΩ |
| Coding | A – standard |
| Standards/regulations | M8 connector IEC 61076-2-104 |
| Status display | No |
| Overvoltage category | II |
| Degree of pollution | 3 |
| Connection method | Individual wires |
| Torque | 1 Nm … 1.5 Nm (Installation-side) |
| Mounting type | Rear mounting M8 x 1 With flat nut |
Material
| Flammability rating according to UL 94 | HB |
|---|---|
| Contact material | Cu alloy |
| Contact surface material | Au |
| Contact carrier material | PUR / PA 6.6 |
| Material, knurls | Nickel-plated brass |
| Sealing material | FKM |
| Additional material specifications | EP (Grout material) |
Cable
| Cable type | PVC litz wire |
|---|---|
| Conductor cross section | 0.25 mm² |
| AWG signal line | 24 |
| Conductor structure signal line | 7x 0.20 mm |
| Core diameter including insulation | 1.5 mm ±0.1 mm |
| Thickness, insulation | 0.21 mm |
| Wire colors | brown, blue, black |
| Material conductor insulation | PVC / UL |
| Conductor material | Tin-plated Cu litz wires |
| Standards/specifications | M8 connector IEC 61076-2-104 |
| Insulation resistance | ≥ 20 MΩ*km |
| Conductor resistance | ≥ 80 Ω/km |
| Nominal voltage, cable | 300 V |
| Test voltage, cable | 2000 V AC |
| Ambient temperature (operation) | -40 °C … 105 °C (cable, fixed installation) |
| -10 °C … 105 °C (cable, flexible installation) |
