Key Commercial Data
| Orderkey | 1419630 |
|---|---|
| Packing unit | 10 pc |
| Minimum order quantity | 10 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4055626189482 |
| Weight per Piece (excluding packing) | 9.180 g |
| Custom tariff number | 79070000 |
| Country of origin | DE (Germany) |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 85 °C (Plug / socket) |
|---|---|
| -40 °C … 85 °C (without mechanical actuation) | |
| Degree of protection | IP67 (correctly plugged in and locked) |
General
| Note | The electrical and mechanical data specified assume that the connector pair is correctly locked and mounted. If the connector is unlocked and if there is a danger of pollution, the connector must be sealed using a protective cap > IP54. The M12 housing screw connection can only be used in conjunction with mating connectors and protective caps with M12 standard thread. Mating connectors with SPEEDCON thread cannot be used. |
|---|---|
| Standards/regulations | M12 connector IEC 61076-2-101 |
| Insertion/withdrawal cycles | > 100 |
| Torque | 0.6 Nm (Tightening torque of mating connector) |
| Mounting type | Rear mounting 2-section, lockable |
Material
| Flammability rating according to UL 94 | V0 |
|---|---|
| Sealing material | FKM (Form seal) |
| Additional material specifications | Zinc die-cast, nickel-plated (Threaded sleeve) |
Standards and Regulations
| Standard designation | M12 connector |
|---|---|
| Standards/regulations | IEC 61076-2-101 |
| Flammability rating according to UL 94 | V0 |
