Key Commercial Data
| Orderkey | 1530663 |
|---|---|
| Packing unit | 1 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 275 (C-2-2017) |
| GTIN | 4017918993429 |
| Weight per Piece (excluding packing) | 266.920 g |
| Custom tariff number | 85444290 |
| Country of origin | DE (Germany) |
General
| Rated voltage | 24 V DC |
|---|---|
| Max. operating voltage Umax | 30 V DC |
| Current carrying capacity per I/O signal | 1 A |
| Current carrying capacity per slot | 1 A |
| Total rated current | 3 A |
| Number of positions | 3 |
| Number of slots | 4 |
| Flammability rating according to UL 94 | V0 |
| Sensor/actuator connection system | M5 socket |
Ambient conditions
| Degree of protection | IP67 |
|---|---|
| Ambient temperature (operation) | -25 °C … 80 °C |
| -30 °C … 70 °C (cable, fixed installation) | |
| -5 °C … 70 °C (cable, flexible installation) |
Master cable data/connection data
| Connection method | Fixed connection |
|---|---|
| Length of cable | 5 m |
| Cable type | Master cable suitable for flexible cable conduit |
| Signal line cross section | 8x 0.25 mm² |
| Power supply cross section | 2x 0.5 mm² |
| External diameter | 6 mm |
| Max. bending cycles | 1000000 |
Insulation material
| Housing material | PA-GF |
|---|---|
| Contact material | CuZn |
| Contact surface material | Ni/Au |
| Contact carrier material | PA |
| Material of threaded sleeve | Cu alloy |
| Material of threaded sleeve surface | Nickel-plated |
