Key Commercial Data
| Orderkey | 3191039 |
|---|---|
| Packing unit | 5 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 578 (C-3-2013) |
| GTIN | 4017918093440 |
| Weight per Piece (excluding packing) | 76.260 g |
| Custom tariff number | 85389099 |
| Country of origin | PL (Poland) |
General
| Number of levels | 1 |
|---|---|
| Number of connections | 16 |
| Color | gray |
| Insulating material | PA |
| Flammability rating according to UL 94 | V0 |
| Rated surge voltage | 4 kV |
| Degree of pollution | 3 |
| Overvoltage category | III |
| Insulating material group | I |
| Nominal current IN | 5 A |
| Max. load current | 5 A |
| Nominal voltage UN | 250 V |
| Open side panel | No |
| Number of positions | 1 |
Connection data
| Conductor cross section solid min. | 0.22 mm² |
|---|---|
| Conductor cross section solid max. | 0.56 mm² |
| Conductor cross section flexible min. | 0.22 mm² |
| Conductor cross section flexible max. | 0.56 mm² |
| Conductor cross section AWG min. | 24 |
| Conductor cross section AWG max. | 20 |
| Conductor cross section flexible, with ferrule with plastic sleeve min. | 0.25 mm² |
| Conductor cross section flexible, with ferrule with plastic sleeve max. | 0.5 mm² |
| Connection method | TERMI-POINT® |
| TERMI-POINT pin dimensions | 2.4 x 0.8 mm |
| Position of the TERMI-POINT pin | vertical |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
