Ambient conditions
| Ambient temperature (operation) | -20 °C … 55 °C |
|---|---|
| Ambient temperature (storage/transport) | -25 °C … 85 °C |
| Permissible humidity (operation) | 100 % |
| Permissible humidity (storage/transport) | 95 % (non-condensing) |
| Air pressure (operation) | 860 hPa … 1080 hPa (up to 1500 m above sea level) |
| Air pressure (storage/transport) | 660 hPa … 1080 hPa (up to 3500 m above sea level) |
| Degree of protection | IP65/IP67 |
| Note | Seal unused slots/connections to ensure the degree of protection. |
General
| Mounting type | Wall mounting |
|---|---|
| Net weight | 1180 g |
| Note on weight specifications | without plug or mounting plate |
| Note | Seal unused slots/connections to ensure the degree of protection. |
| Mounting type | on mounting plate |
Interfaces
| Designation | PROFINET |
|---|---|
| No. of channels | 2 |
| Connection method | VARIOSUB push-pull connectors |
| Transmission speed | 10/100 Mbps (auto negotiation) |
| Transmission physics | FO |
Power supply for module electronics
| Connection method | VARIOSUB push-pull connectors |
|---|---|
| Designation | US1 |
| Supply voltage | 24 V DC |
| Supply voltage range | 18.5 V DC … 30 V DC (including ripple) |
| Ripple | Max 3.6 VSS within the permissible voltage range |
