Key Commercial Data
| Orderkey | 2902647 |
|---|---|
| Packing unit | 1 pc |
| Catalog page | Page 274 (C-5-2017) |
| GTIN | 4046356668880 |
| Weight per Piece (excluding packing) | 16.560 g |
| Custom tariff number | 85363010 |
| Country of origin | DE (Germany) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Input data
| Nominal input voltage UN | 24 V DC (AC operation only permitted for RIF-1) |
|---|---|
| Input voltage range in reference to UN | 0.4 … 1.2 |
| Input voltage range | |
| Mains frequency | 50 Hz |
| 60 Hz | |
| Status display | Yellow LED |
| Protective circuit/component | Varistor |
| Surge voltage protection | > 56 V |
Output data
| Limiting continuous current | ≤ 250 mA (Relay coil current) |
|---|---|
| Voltage drop at max. limiting continuous current | < 100 mV |
General
| Setting accuracy | 3 % (of scale end value) |
|---|---|
| Repeat accuracy | 1 % |
| Insulation | Basic insulation |
| Standards/regulations | DIN EN 50178 |
| Overvoltage category | I |
| Degree of pollution | 2 |
| Mounting position | any |
| Assembly instructions | Can be inserted into relay base |
Ambient conditions
| Ambient temperature (operation) | -25 °C … 50 °C (RIF-1, AC coil, 2 PDTs at 6 A) |
|---|---|
| -25 °C … 50 °C (RIF-1, DC coil, 2 PDTs at 5 A) | |
| -25 °C … 40 °C (RIF-2, DC coil, 2 PDTs at 8 A) | |
| -25 °C … 40 °C (RIF-2, DC coil, 4 PDTs at 5 A) | |
| -25 °C … 40 °C (RIF-3, DC coil, 3 PDTs at 6.75 A) | |
| -25 °C … 40 °C (RIF-3, DC coil, 2 PDTs at 8 A) | |
| -25 °C … 35 °C (RIF-4, DC coil, 3 PDTs at 8 A) | |
| -25 °C … 25 °C (RIF-4, DC coil, 3 N/O contacts at 8 A) | |
| Ambient temperature (storage/transport) | -25 °C … 85 °C |
