Key Commercial Data
| Orderkey | 1021715 |
|---|---|
| Packing unit | 10 pc |
| Minimum order quantity | 10 pc |
| Note | Made to Order (non-returnable) |
| GTIN | 4055626514543 |
| Weight per Piece (excluding packing) | 100.000 g |
| Custom tariff number | 85364900 |
| Country of origin | PL (Poland) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -40 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
Coil side
| Nominal input voltage UN | 230 V AC |
|---|---|
| Input voltage range in reference to UN | see diagram |
| Mains frequency | 50/60 Hz |
| Typical input current at UN | 6.5 mA |
| Typical response time | 5 ms … 15 ms |
| Typical release time range | 5 ms … 20 ms |
| Coil voltage | 230 V AC |
| Operating voltage display | Yellow LED |
Contact side
| Contact type | 4 PDTs |
|---|---|
| Type of switch contact | Single contact |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC/DC |
| Minimum switching voltage | 5 V (24 mA) |
| Min. switching current | 5 mA (24 V) |
| Maximum inrush current | 16 A (20 ms, N/O contact) |
| Limiting continuous current | see diagram |
| Interrupting rating (ohmic load) max. | 144 W (24 V DC) |
| 124 W (48 V DC) | |
| 108 W (60 V DC) | |
| 52 W (at 110 V DC) | |
| 48 W (220 V DC) | |
| 1500 VA (250 V AC) | |
| Switching capacity min. | 0.12 W |
| Switching capacity | 2 A (24 V, DC13) |
| 1 A (230 V, AC15) |
