Key Commercial Data
| Orderkey | 2900932 |
|---|---|
| Packing unit | 10 pc |
| Catalog page | Page 313 (C-5-2017) |
| GTIN | 4046356733168 |
| Weight per Piece (excluding packing) | 68.000 g |
| Custom tariff number | 85366990 |
| Country of origin | CN (China) |
Ambient conditions
| Ambient temperature (operation) | -40 °C … 85 °C (Depends on application/assembly) |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
Connection data, input side
| Connection name | Input side |
|---|---|
| Connection method | Screw connection |
| Stripping length | 8 mm |
| Conductor cross section solid | 0.5 mm² … 4 mm² |
| Conductor cross section flexible | 0.5 mm² … 4 mm² |
| 0.5 mm² … 4 mm² (Ferrule with plastic sleeve) | |
| Conductor cross section flexible (2 conductors with same cross section) | 0.5 mm² … 2.5 mm² |
| 0.5 mm² … 1.5 mm² (TWIN ferrule with plastic sleeve) | |
| Conductor cross section AWG | 20 … 10 (solid) |
| 20 … 12 (flexible) | |
| Torque | 0.5 Nm … 0.6 Nm |
Connection data, output side
| Connection name | Contact side |
|---|---|
| Connection method | Screw connection |
| Stripping length | 8 mm |
| Conductor cross section solid | 0.5 mm² … 4 mm² |
| Conductor cross section flexible | 0.5 mm² … 4 mm² |
| 0.5 mm² … 4 mm² (Ferrule with plastic sleeve) | |
| Conductor cross section flexible (2 conductors with same cross section) | 0.5 mm² … 2.5 mm² |
| 0.5 mm² … 1.5 mm² (TWIN ferrule with plastic sleeve) | |
| Conductor cross section AWG | 20 … 10 (solid) |
| 20 … 12 (flexible) | |
| Torque | 0.5 Nm … 0.6 Nm |
