Key Commercial Data
| Orderkey | 2908215 |
|---|---|
| Packing unit | 10 pc |
| Catalog page | Page 456 (C-5-2017) |
| GTIN | 4055626289151 |
| Weight per Piece (excluding packing) | 71.520 g |
| Custom tariff number | 85364110 |
| Country of origin | CZ (Czech Republic) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -20 °C … 50 °C |
|---|---|
| Ambient temperature (storage/transport) | -20 °C … 70 °C |
Coil side
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range in reference to UN | see diagram |
| Typical input current at UN | 30 mA |
| Typical response time | 10 ms |
| Typical release time | 10 ms |
| Coil voltage | 24 V DC |
| Protective circuit | Damping diode |
| Operating voltage display | Yellow LED |
| Power dissipation for nominal condition | 0.72 W |
Contact side
| Contact type | 2 changeover contacts, forcibly actuated |
|---|---|
| Type of switch contact | Single contact |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC/DC |
| Minimum switching voltage | 15 V AC/DC |
| Min. switching current | 10 mA |
| Maximum inrush current | 6 A |
| Limiting continuous current | 6 A |
| Interrupting rating (ohmic load) max. | 144 W (at 24 V DC) |
| 288 W (at 48 V DC) | |
| 88 W (at 110 V DC) | |
| 110 W (at 220 V DC) | |
| 1500 VA (for 250 V AC) | |
| Switching capacity | 2 A (at 24 V, DC13) |
| 3 A (at 230 V, AC15) |
