Key Commercial Data
| Orderkey | 2905289 |
|---|---|
| Packing unit | 10 pc |
| Catalog page | Page 344 (C-5-2017) |
| GTIN | 4046356945448 |
| Weight per Piece (excluding packing) | 68.140 g |
| Custom tariff number | 85364110 |
| Country of origin | CN (China) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -40 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
Coil side
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range in reference to UN | see diagram |
| Typical input current at UN | 18 mA |
| Typical response time | 9 ms |
| Typical release time | 10 ms |
| Coil voltage | 24 V DC |
| Protective circuit | Damping diode |
| Operating voltage display | Yellow LED |
| Power dissipation for nominal condition | 0.43 W |
Contact side
| Contact type | 1 PDT |
|---|---|
| Type of switch contact | Single contact |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC/DC |
| Minimum switching voltage | 12 V (at 10 mA) |
| Min. switching current | 10 mA (at 12 V) |
| Maximum inrush current | 24 A (20 ms, N/O contact) |
| Limiting continuous current | see diagram |
| Interrupting rating (ohmic load) max. | 264 W (at 24 V DC) |
| 62 W (at 48 V DC) | |
| 48 W (at 60 V DC) | |
| 52 W (at 110 V DC) | |
| 66 W (at 220 V DC) | |
| 2500 VA (for 250 V AC) | |
| Switching capacity min. | 120 mW |
| Switching capacity | 2 A (at 24 V, DC13) |
| 3 A (at 230 V, AC15) |
