Key Commercial Data
| Orderkey | 2905656 |
|---|---|
| Packing unit | 10 pc |
| Note | Made to Order (non-returnable) |
| Catalog page | Page 339 (C-5-2017) |
| GTIN | 4046356983518 |
| Weight per Piece (excluding packing) | 27.990 g |
| Custom tariff number | 85364110 |
| Country of origin | JP (Japan) |
Note
| Utilization restriction | EMC: class A product, see manufacturer’s declaration in the download area |
|---|
Ambient conditions
| Ambient temperature (operation) | -25 °C … 60 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
| Degree of protection | IP20 |
Input data
| Input voltage range | 19.2 V DC … 28.8 V DC |
|---|---|
| Rated actuating voltage UC | 24 V DC |
| “0” signal switching threshold in reference to UC | < 0.4 |
| “1” signal switching threshold in reference to UC | > 0.8 |
| Typical response time | 10 ms |
| Typical turn-off time | 10 ms |
| Status display | Yellow LED |
| Type of protection | Free-wheeling diode |
| Transmission frequency | 10 Hz |
| Power dissipation for nominal condition | 0.19 W |
Output data
| Output voltage range | 24 V AC … 253 V AC (50/60 Hz) |
|---|---|
| Limiting continuous current | 0.75 A (see derating curve) |
| Maximum inrush current | 30 A (10 ms) |
| Min. load current | 10 mA |
| Leakage current | 1 mA (in off state) |
| Surge current | 30 A AC (tp = 20 ms, at 25°C) |
| Max. load value | 4.5 A2s (tp = 10 ms, at 25 °C) |
| Surge voltage protection | > 275 V |
| Voltage drop at max. limiting continuous current | < 1 V |
| Output circuit | 2-wire, zero voltage switch |
| Type of protection | RCV circuit |
