Key Commercial Data
| Orderkey | 2908180 |
|---|---|
| Packing unit | 10 pc |
| Minimum order quantity | 10 pc |
| Catalog page | Page 308 (C-5-2017) |
| GTIN | 4055626277899 |
| Weight per Piece (excluding packing) | 18.000 g |
| Custom tariff number | 85364190 |
| Country of origin | CN (China) |
Ambient conditions
| Ambient temperature (operation) | -40 °C … 70 °C |
|---|---|
| Ambient temperature (storage/transport) | -40 °C … 85 °C |
Coil side
| Nominal input voltage UN | 24 V DC |
|---|---|
| Input voltage range in reference to UN | 0.8 … 2.2 (see diagram) |
| Typical input current at UN | 17 mA |
| Typical response time | 9 ms |
| Typical release time | 6 ms |
| Power dissipation for nominal condition | 0.41 W |
Contact side
| Contact type | 1 PDT |
|---|---|
| Type of switch contact | Single contact |
| Contact material | AgNi |
| Maximum switching voltage | 250 V AC/DC |
| Minimum switching voltage | 12 V (at 10 mA) |
| Min. switching current | 10 mA (at 12 V) |
| Maximum inrush current | 32 A (20 ms) |
| Limiting continuous current | 16 A |
| Interrupting rating (ohmic load) max. | 384 W (at 24 V DC) |
| 62 W (at 48 V DC) | |
| 48 W (at 60 V DC) | |
| 53 W (at 110 V DC) | |
| 66 W (at 220 V DC) |
General
| Test voltage relay winding/relay contact | 5 kV AC (50 Hz, 1 min.) |
|---|---|
| Operating mode | 100% operating factor |
| Degree of protection | RT II |
| Mechanical service life | 5x 106cycles |
| Service life, electrical | see diagram |
| Mounting position | any |
| Net weight (SAP) | 18 g |
